That Belt Doesn’t Fit You

Michelle, Positively Riveting

Have you ever grabbed a belt and realized it was the wrong size?

You keep pulling and pulling until you finally get enough cinching around your waist to make it work. Then you realize the hole doesn’t line up, so now you’re creating a new hole just to fasten it. Sure, eventually you get the belt tight. But that doesn’t mean it actually fits.

Blind rivets work much the same way.

One of the biggest misconceptions in blind riveting is that if the rivet fits in the hole and breaks, the application is fine.

Not necessarily.

A rivet can technically “work” while still being completely wrong for the substrate stack it’s fastening.

And this is where people get fooled.

When the substrate thickness is too thin compared to the rivet length, the mandrel end has to travel farther before the rivet body compresses enough to reach break load. In simple terms, the tool just keeps pulling and pulling and pulling waiting for the rivet to finally cinch enough to break correctly.

That’s what low-side grip range looks like.

A lot of times, the rivet still sets, so people assume everything is okay. But there are costs to that condition.

Longer rivets cost more money because there’s simply more material involved. Cycle times can increase. Blind-side protrusion can become excessive. Now, that extra-long tail sticking out on the blindside and into your product starts mattering.

Is there wiring behind it?
A circuit board?
A moving component?
Something that can snag on that protrusion later?

That’s why grip range isn’t just about whether the rivet fits in the hole. It’s about whether the rivet actually fits the application.

Then we flip to the scarier side of grip range.

This is the opposite condition from a substrate that’s too thin. This is when your substrate is too thick—or something is wrong with the rivet body itself—and now you end up with a high break.

That’s the sharp edge sticking out of the rivet after installation. Sometimes it’s subtle. Sometimes it’s standing straight out of the material like a needle.

Either way, it’s bad news.

What’s happening mechanically here is completely different from low-side grip range. In this case, the mandrel doesn’t have enough travel to properly reach break load before the system maxes out. The moment you pull the trigger, the rivet is already under extreme load.

That little ball end on the mandrel can’t move where it needs to because the substrate thickness is physically in the way. So, instead of the mandrel reaching proper break load and snapping correctly, the tool basically bites it off.

The rivet isn’t really breaking normally anymore. It’s tearing.

Now you’ve got sharp edges, massive rework, and operators trying to compensate for a condition that probably shouldn’t exist in the first place. And if this is a consumer-facing product?

That’s a nightmare.

The reality is, grip range itself isn’t complicated. Most of the time, nobody is hiding information from you. The problem is usually that nobody stopped to validate whether the application still matches the original rivet specification.

And manufacturing changes over time.

A washer gets added. A material changes. Paint thickness changes. A process moves from pre- paint to post-paint. Suppliers change tolerances. Little changes happen over the years and eventually the substrate stack is no longer what the original rivet specification was designed around.

But the print stays the same.

A lot of plants feel trapped by that print because the documentation may predate everybody currently working there. People assume they can’t question it. Meanwhile, the application itself may have drifted far enough that the rivet is no longer operating in the grip range it was intended for.

That matters.

Because once a rivet falls outside its intended grip range, you start creating problems that people often blame on the tool, the operator, or maintenance. Multiple pulls. High breaks. Rework. Sharp edges. Compensation behaviors. Tool complaints.
A lot of the time, the rivet simply doesn’t match the stack anymore.

And if it doesn’t?

Move to the next grip range that does.
Because at the end of the day, the question isn’t just: “Does the rivet fit in the hole?”

The real question is:

Does the belt fit you?

-MD
