Phillips Drive System: PHILLIPS SQUARE-DRIV®
One drive system with five choices of engagement
The benefits of the PHILLIPS SQUARE-DRIV® combination drive system are significant. In larger, higher torque applications where stick-fit and off-angle driving are crucial, PHILLIPS SQUARE-DRIV® is especially useful. Fasteners can be better controlled at higher torque levels for optimum clamp loads. This reduces driver bit wear and eliminates driver cam-out which can cause recess reaming, component damage/rework and operator injury. The stabilizing ribs in the recess and driver bit ensure a class leading stable fit and further help eliminate cam-out. In field service operations, versatility is the mark of the PHILLIPS SQUARE-DRIV® combination drive system. A single drive system allows the use of five different drivers: PHILLIPS SQUARE-DRIV®, PHILLIPS II®, POZIDRIV®, Square, and Generic Phillips.
DRIVER SIZES
0-1 THRU 3-3
SCREW SIZES
M3 (#4) THRU M6 (1/4 IN)
Features & Benefits
Recess to driver fit engineered to ensure screw sticks securely to driver bit
-Reliable one-handed application of screws at point of assembly
-Magnetic bits or vacuum screw holders not necessary
-Virtually eliminates dropped screws in assembly area and on factory floor
ACR® technology
-Significantly enhances driving torque capability
-Aids in disassembly for more effective maintenance and service
Only three driver bit sizes required to cover the most popular size-range
-Extends driver bit life
Distinctive head marking that easily identifies a PHILLIPS SQUARE-DRIV® Drive System
Phillips Screw Company quality inspections
-Assures global system quality and compatibility
This information was provided entirely by The Phillips Screw Company
